Quality Offset Ink For High And Medium Speed Printing
Introduction
The latest European technology system develops ECOO-INK-C printing ink. It is made from polymeric, high-soluble resin, and a newly-invented paste pigment. This product is suitable for printing packaging, advertisements, labels, high-quality brochures, and decorative products on art paper, coated paper, offset paper, cardboard, etc., and especially for medium and high-speed printing.
Specification
| Type | ECOO-INK-C |
| Packing | 1kg/vacuum tin, 12tins/carton |
| Shelf Life | 3 years(from the production date); Product against light and water |
| ITEM/TYPE | TACK
VALUE | FLUIDITY
(mm) | PARTICLE
SIZE (μm) | GLOSS | SETTING
TIME (min) | DRYING
TIME (hr) | SKINNING TIME (hr) |
C
YELLOW | 8-9 | 39±1 | 12.5 | 85 | 4 | < 8-10 | > 30 |
C
MAGENTA | 8.5-9.5 | 40±1 | 12.5 | 75 | 4 | < 8-10 | > 30 |
C
CYAN | 8.5-9.5 | 39±1 | 12.5 | 75 | 4 | < 8-10 | > 30 |
C
BLACK | 9-10 | 38±1 | 12.5 | 80 | 4 | < 8-10 | > 30 |
| Tack value | The value is measured in 1 minute by an inkometer at 32ºC and 400rpm. |
| Set time | Printing adapter, 157g art paper, the volume of ink-coating can be up to 0.125cc |
| Condition of test | Room temperature 25ºC, humidity 65%-75% |
| ITEM/TYPE | Light
Resistance | Heat
Resistance | Acid
Resistance | Alkaline
Resistance | Alcohol
Resistance | Soap
Resistance |
C
YELLOW | 3-4 | 5 | 5 | 4 | 4 | 4 |
C
MAGENTA | 3-4 | 5 | 5 | 5 | 4 | 5 |
C
CYAN | 6-7 | 5 | 5 | 5 | 5 | 5 |
C
BLACK | 6-7 | 5 | 5 | 5 | 5 | 5 |
| Lightfastness | 1-8 (weak-strong) |
| Others | 1-5 (weak-strong) |
Features
Printing speed: 12000rph-15000rph
Environment friendly
Anti-skinning performance
Good water/ink balance
Rich in printing layer
Clear and complete in printing dots
Quick-drying performance, quick setting, quick turn
Producing And Packaging
Our factory is located in Shanghai. It has two producing plants and an independent oil-producing line. The productivity reaches up to 4000000 tons. It is certified by ISO, Rohs. You can visit at any time.
Certificates
EcooGraphix series Printing Inks have passed the China environmental label product certification(ten central certifications), ISO9001 quality management system, ISO14001 environmental protection system certification, ROHS certification and REACH certification, American ASTM, CPSIA and other related safety testing and certification, and the SONY SGS certification.
Tips
Tips before ink processing and after processing.
Do not judge the color of ink by the looking into the package only. All inks appear in thick layers the container darker and dirtier as in the print. You may mistake the black to the blue or red. You may find bubbles in the ink which is nitrogen mixed in to exclude oxidative drying problems. Do not worry, the bubbles will disappear on the rolls of the inking unit and will not lead to printing problems.
During longer print interruptions the rolls have to be cleaned and ink in the ink duct has to be sprayed on with antioxidants.
Remove skin whenever you find it in the opened container regardless of how small the skin is.
Inks which was mixed with printing aids should not filled back to the original ink.
FAQ
| Q1: What to do for specific color requirements from our company?
A: We offer customers inks in specific colors or ink with specific characteristics sometimes, like drying speed, smell, resistance to fading, and gloss. Please send us a detailed ink sample or Pantone no# so that we can produce it carefully for you. |
| |
| Q2: How to store offset printing ink?
A: The ideal process and storage temperature for offset inks is between 18ºC-25ºC. If the offset inks are too high in viscosity due to storing at low temperatures problems may occur due to insufficient flow in the duct and picking at sensitive stocks. If the inks will be processed in higher temperatures, so because of low viscosity misting, ink/water problems or high sot gain may occur.
The ink cans have to be stored vertically standing under the exclusion of daylight.
|
| |
| Q3: Can I visit your factory?
A: You are warmly welcome to visit our factory! Our company is in Hangzhou city, which is about 1.5 hours by train from Shanghai.
|
| |
| Q4: Can I take my brand and label on the packing?
A: Yes, we can provide the OEM with the customer's brand and label.
|
