4kw Automatic Film Lamination Window Patching Machine For Box

Name: 4kw Automatic Film Lamination Window Patching Machine For Box
Brand: EcooGraphix
Price: 1 USD

Wholesale 4kw Automatic Film Lamination Window Patching Machine For Box from china suppliers

Brand Name : EcooGraphix

Model Number : Ecoo-TC1100 & Ecoo-TC1000

Certification : CE

Place of Origin : China

MOQ : 1SET

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 500 Sets/ Year

Packaging Details : Standard Exporting Package: Polywood Carton

Product Name : Automatic Window Patching Machine For Box

Producting Style : 1-Lane Operation, 2-Lane Operation

Outer Diameter : <=500mm

Length a of The Blank Paper(mm) : 100-900, 100-900; 100-420, 100-420

Main Motor Power : 4kw

Width B of The Blank Paper(mm) : 80-1100, 80-530; 100-750, 100-380

Specification : 5600(L)x2000(W)x1500(H)mm;4800(L)x1600(W)x1500(H)mm

Contact Now

Automatic Window Film Lamination Window Patching Machine For Box

Features

Ecoo TC-1100, TC-1000 automatic window patching machines are special equipment for carton box,
color box window lamination; They are advanced models in domestic market. Perfect personalization design
philosophy ensures the machines have the feature of high efficiency, high-precision, high stability and easy operation.

These machines are available for both cardboard and corrugated paper. Adopting servo feeder, flexible version
module of glue print, stable and accurate diaphragm incision and cross cutting cropped to achieve tissue boxes,
gift boxes, toy boxes, shirt boxes, milk cartons and other window film lamination.

Specification

Window Patching Machine
Model	Ecoo-TC1100		Ecoo-TC1000
The producting style	1-lane operation	2-lane operation	1-lane operation	2-lane operation
Length A of the blank paper	100mm-900mm	100mm-900mm	100mm-420mm	100mm-420mm
Width B of the blank paper	80mm-1100mm	80mm-530mm	100mm-750mm	100mm-380mm
Length window/lining material C	80mm-760mm	80mm-760mm	80mm-280mm	80mm-280mm
Width window/lining material C	30mm-940mm	30mm-380mm	30mm-550mm	30mm-220mm
Speed of the machine	≤200pcs/min	≤400pcs/min	≤200pcs/min	≤400pcs/min

Carton weight
Carton	180g/m2-600g/m2
Corrugated	≤1.5mm
Film thickness
PVC, PE, PS	0.05mm-0.3mm
PET	0.05mm-0.2mm
Outer diameter	≤500mm
Inner diameter	70mm-80mm
The size of the machine	5600(L)x2000(W)x1500(H)mm/4800(L)x1600(W)x1500(H)mm
Main motor power	4kw
Total power	22kw

4kw Automatic Film Lamination Window Patching Machine For Box

Producing And Packaging

FAQ

Q: What about the Installation and after-sales technician support?

A: Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets and service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours.
Among our large amount of CTP installations worldwide, there are also many end users (printers) who have purchased the CTP products from EcooGraphix China directly and EcooGraphix technical service team support these installations remotely with regular onsite visits.
These end users Printers all run the CTP systems with full satisfaction due to our robust quality, seamless remote service, thorough training and maintanence. If you are a printer who is considering purchasing directly from EcooGraphix China, there is no hasle on installations, training and after sales service. We guarantee your satisfaction.
