Processless Chemistry DOP Plate Negative Working Thermal Plate

Name: Processless Chemistry DOP Plate Negative Working Thermal Plate
Brand: Ecoographix
Price: 4.7 USD

Brand Name : Ecoographix

Model Number : ECOO-G

Certification : ISO, CE

Place of Origin : China

MOQ : 1000 sqm

Price : usd 4.7 per sqm

Payment Terms : L/C, T/T

Supply Ability : 1000000 sqm each year

Delivery Time : 40 days

Packaging Details : 50 sheets per carton with protection frame

Model : ECOO-G

Plate type : thermal plate negative working

Laser wavelength : 800*850 nm

Start up paper : less than 50 sheets with fountain solution

Developer : no need of developer

Shlef life : 12 months

Contact Now

Negative working processless chemistry-free DOP plate-ECOO--G

Brief introuduction
ECOO-G is processless plate, which could be applied to printing machine directly after imaging without processing. Thus, it shorten the prepress procedures and save cost of developing and water treatment. The skip of developer also fits the trend of being envoronment friendly. Thus, it has more and more popularity.
Features
- negative writing thermal plate
- develops on press
- made with high grade aluminum from Europe
- eliminates need for processor and chemistry
- non-ablative coating
- run lengths up to 100, 000 impressions
- UV Ink up to 30, 000 impressions
- ability to print both AM and FM screening

Technical data

Model	ECOO-G
Plate Type	thermal-negative type
Application	High grade commercial, newspaper and package printing
Substrate	Electrolyte graining and Anodized AL substrate
Thickness	0.15mm / 0.30mm
Maximum short grain width	Maximum width 1280 mm
Spectrum sensitivity	800-850 nm
Photosensitive wave length	830 nm
Platesetter	Various dominant thermal platesetters in the market
Coating color	Light Grey
Low-energy imaging	130-150 mj/ m²
The period of latent image stabilization	≤7 days
Recommended screen method	1-99% @200 LPI AM or 20μm FM or mixture
The paper number of start-up	<20 sheets (fountain solution conductivity: 2000-3000μS, PH at lower range between 4-5)
Safety light	Ambient light(<800 LUX) up to 4 hours
Processing	Without processing, directly on press
Run Length	100,000 impressions Actual run length depends on printing conditions
Shelf life	12 months with original sealed packaged
Transportation	Packed in seal and stored by means of prevention from light, moisture, overheat and high humidity
Storage	Recommended condition: 18℃-24℃, 40%-50% RH.

Advantages
- no processor required
- no chemistry to deal with
- elimination of processing time equates to more time available for other work
- price point makes this competitive with the AGFA Azura TS, FUJI Ecomaxx-T, Kodak Sonora XP

Benefits
- savings on chemistry and processor
- make-ready sheets savings
- savings on energy and water consumption
- quicker turn-around time on press
- frees up space in shops with space limitations

Application
*Suitable for sheet-fed offset press or high speed rotary offset press
*Run length: 100, 000 impressions
*Suitable for different types of traditional inks and fountain solutions, including alcohol's substitutes as fountain
Solutions.
*Unsuitable to improve run length by baking plates.

Contrast details

plate structure

FAQ
1. is a freezer container needed for the shipment?
No. It can be shipped by general container. When you receive the plate, please kindly store in air conditioned warehouse.
2. how long is the shelf life?
12 months in air conditioned warehouse. We recommend to use it within 10 months.
3. how about the lead time?
Normally 30-45 days.
